ROWE 12020J-6

ROWE 12020J-6
Contact us for price
Description
The ROWE 12020J-6 is a reliable used coil cradle designed to support heavy-duty coil feeding tasks. Capable of handling coils up to 12,000 pounds with a maximum width of 20 inches, it is well-suited for various industrial applications. The unit features a 3 HP motor that operates on a 3-phase, 60-cycle power supply, allowing for adjustable speeds to align with production demands. Equipped with adjustable guide plates and stock guides, the ROWE 12020J-6 ensures precise coil alignment, enhancing workflow efficiency. Its slack loop feature effectively manages coil slack, supporting a feed rate from 35 to 100 feet per minute. The control system operates on a 110V power supply, facilitating seamless integration into existing processes. Constructed with durability in mind, the machine is designed for consistent performance, even under demanding conditions, making it a dependable choice for managing coil feeding duties. The ROWE 12020J-6 also includes two main power-driven rolls, two coil retaining rolls, and two driven pinch rolls, all of which are hardened and polished for durability and precision. It accommodates a maximum coil diameter of 60 inches and supports stock thickness from .023” to .125”, with performance varying based on thickness. Note that stocks below .023” thickness are not recommended.
Specifications
Manufacturer | ROWE |
Model | 12020J-6 |
Condition | Used |
Serial Number | 18203 |
Stock Number | 4384 |
Conditon | Used |
Coil capacity | 12,000 LBS |
Max coil od | 60" |
Max coil width | 20" |
Standard feed rate | 35 - 100 F.P.M. |
Motor | 3 HP, 3 PHASE, 60 CYCLE |
Max material width | 0.125" |
