1998 FEED LEASE VARIOUS
Sold
1998 FEED LEASE VARIOUS
$109,900 (USD)
Description
36" X 20,000 LB FEED LEASE FEED LINE
(5) Roll Straightener - 5” Diameter
Backed Up Straightening Rolls
Feed Lease Model R-20M-36 Three Arm Reel
Model LC-20M-36 Load Car
2 HP Thread Drive
Feeds Left to Right
Equipped With:
Hydraulic Pinch Roll
Hydraulic Coil Restrictor With Powered Roll
Hydraulic Coil End Bender - Model CEB-36
(5) Containment Rolls in Chute & Funnel
Guide Assembly At Exit End
Tip Up Deflector Chute to Open Away From Load Car
HYPR-10 Hydraulic Tilting Pinch Roll Assembly
FULLY OPERATIONAL, PAINTED AND READY TO GO
Specifications
| Manufacturer | FEED LEASE |
| Model | VARIOUS |
| Year | 1998 |
| Condition | Used |
| Serial Number | 4425 |
| Stock Number | 4295 |
| Conditon | Used |
| Feed lease model | FLPS-5-36-5 Powered Straightener |
| Min. & max. stock thickness | .079” @ 35” Wide / .675” @ 8 3/8” Wide |
| Material width | 35” |
| Pinch rolls | 6 1/2” Diameter - Crodon |
| Coil capacity | 20,000 Lbs |
| Coil width | 36” |
| Coil i.d. | 20” - 24” |
| Coil o.d. | 72” |
| Passline | 66” |
| Approx. line speed | 10 - 70 FPM |
| Approx. overall dimensions | 371” L-R x 169” F-B x 172” High |
