2000 SUTHERLAND SP2-D300-120-60-12
2000 SUTHERLAND SP2-D300-120-60-12
Contact us for price
orCall +1 517-731-0073
Description
330 TON SUTHERLAND STRAIGHT SIDE DOUBLE CRANK PRESS **CROWN REBUILT IN 2019** REMANUFACTURED GEAR BOX INCLUDING NEW GEAR & REWORKING THE CLUTCH & BRAKE. NEW UPGRADED LOCKING DEVICES ON COUPLES TO CRANKSHAFTS. RETIMED THE PRESS. CLEANED AND POLISHED THE CRANKSHAFTS. REFIT MAIN BEARINGS. FULL INSPECTION ON CROWN CHECKED FOR CRACKS - NONE FOUND. OFFERED WITH 6-MONTH WARRANTY ON THE TORQUE BOX & CLUTCH WORK. EQUIPPED WITH: T-SLOTTED SLIDE & BOLSTER ON 6" CENTERS FREE STANDING CONTROL CONSOLE AIR CLUTCH & BRAKE WINTRISS SMARTPAC 2 8-POINT GIBBING RECIRCULATING LUBE SYSTEM PALM BUTTONS FLOOR STANDING ALSO AVAILABLE AT ADDITIONAL COST: LINEAR TRANSFER SYSTEM
Specifications
Manufacturer | SUTHERLAND |
Model | SP2-D300-120-60-12 |
Year | 2000 |
Condition | Used |
Serial Number | F1386 7300014 |
Stock Number | 4149 |
Conditon | Used |
Capacity | 330 TONS @ .5" ABOVE BOTTOM |
Stroke | 12" |
Shut height over bolster | 30" S.D.A.U. |
Slide adjustment | 10" |
Bed area | 120" LR x 60" FB |
Slide area | 120" LR x 60" FB |
Bolster plate | 120" LR x 60" FB x 7.6" THICK |
Speed | 30-60 SPM |
Approximate overall dimensions | 174" LR x 96" FB x 236" ABOVE FLOOR |
Estimated weight | 165,000 LBS |
