1984 MINSTER TR2-30

1984 MINSTER TR2-30
Contact us for price
Description
The 1984 Minster TR2-30 is a used 30-ton straight-side mechanical press known for its high-speed capabilities, offering a range of 100-1200 strokes per minute. This model is equipped with a Vamco feed, model MV 6, accommodating a maximum width of 6 inches and material thickness of up to 0.062 inches. It features an air clutch and counterbalance, which enhances its operational efficiency. Key specifications include a bolster size of 30 inches left-to-right by 21 inches front-to-back and a shut height adjustable from 6.75 inches to 8.50 inches. The press has a stroke length of 1.25 inches and a slide adjustment capacity of 1.75 inches. Weighing approximately 20,000 lbs, this machine is robust and well-suited for various high-speed press operations.
Specifications
Manufacturer | MINSTER |
Model | TR2-30 |
Year | 1984 |
Condition | Used |
Serial Number | 25786 |
Stock Number | 3981 |
Conditon | Used |
Bolster size | 30''LR x 21''FB |
Shut height | 6.75'' MIN, 8.50'' MAX |
Length of stroke | 1.25'' |
Slide adjustment | 1.75'' |
Capacity | 30 TON |
Approx weight | 20,000 LBS |
