1996 300 TON MINSTER MODEL E2-300 STRAIGHT SIDE MECHANICAL PRESS

1996 300 TON MINSTER MODEL E2-300 STRAIGHT SIDE MECHANICAL PRESS
Description
The 1996 Minster Model E2-300 is a sturdy straight side mechanical press with a robust capacity of 300 tons, making it well-suited for heavy-duty industrial applications. This used machine is designed for efficiency and precision, featuring a bolster area of 84 inches by 48 inches, providing ample space for various operations. The press operates with a stroke length of 12 inches and offers a range of 0 to 80 strokes per minute, allowing for flexibility in production speed. Additionally, it includes a slide adjustment of 6 inches and a shut height of 30 inches SDAU, facilitating versatile tooling adjustments. This offer also includes an upgraded control system and a driveshaft rebuild, enhancing the machine’s reliability and operational capabilities for contemporary manufacturing needs. Overall, this Minster E2-300 is a solid choice for businesses looking for a high-capacity, well-maintained mechanical press that combines strength with dependable performance.
Specifications
| Manufacturer | MINSTER |
| Model | E2-300 |
| Year | 1996 |
| Condition | Used |
| Serial Number | E2-300-24443 |
| Stock Number | 6347 |
| MODEL NUMBER | E2-300 |
| SERIAL NUMBER | E2-300-24443 |
| CAPACITY | 300 TON |
| BOLSTER AREA | 84" LR x 48" FB |
| LENGTH OF STROKE | 12" |
| STROKES PER MINUTE | 0-80 |
| SLIDE ADJUSTMENT | 6" |
| SHUT HEIGHT ON BED, SDAU | 30" |
| Overall Lift clearance | RF-.029 LF .028 |
| Main Clearance | RF-..004 LF .004 |
| Connection Clearance | RF-.007 LF .007 |
| Wrist Pin Clearance | RF-..001 LF .002 |
| Screw and Nut clearance | RF-.015 LF .011 |
| Main Gears / Keys | Keys are tight in Main Gears and Teeth are showing minimal wear |
